　Name ： ET-6722KN Heavy-Duty Oil Pressure Tester Kit
Product Introduction：
ET-6722KN Heavy-Duty Oil Pressure Tester Kit
Product Detail：






ET-6722KN  Heavy-Duty Oil Pressure Tester Kit

  • Helps to diagnose work oil pumps and engines faulty oil pressure switches and warning indicators easy to use.

  • Accurately tests oil pump pressure, switch & warning indicators.

  • Large clear dual scaled gauge 0 – 10 bar.

  • Quick coupling adapters with shut-off valve, for speed & security.

  • Permanently oil primed, long, flexible hose

  • APPLICATIONS: ALFA,MITSUBISHI, AUDI, NISSAN, BMW, OPEL, CTTROEN, PEUGEOT, DAIHATSU, RENAULT, FIAT, ROVER, FORD, SAAB, HONDA, SKODA, HYUNDAI, SUBARU, ISUZU, SUZUKI, JAGUAR, TOYOTA, LADA, VAUXHALL, LANCIA, VW, MAZDA, VOLVO, MERCEDES-BENZ, ZASTAVA




Gauge Assembly:






























































































  Hose overall length Gauge Diameter Scale
A 1300mm 83mm 0-10 bar (0 ~ 150psi)
  Adapters Adapters Thread
B   1/8x28PT
C   1/8x27NPT
D   1/4x18NPT
E   3/8x20UNF
F   1/2x20UNF
G   M10x1.0
H   M12x1.5
I   M14x1.5
J   M16x1.5
K   M18x1.5
L   90∘ELBOW
M   SERVICE KIT
